– Brouwer Telematics allows for remote diagnostics, updates, adjustments and monitoring utilizing GSM/GPS communication

– Compact, Maneuverable Automatic Stacking Roll Harvester with a tight turning radius and easy back up capability

– Advanced Cutter Head with 2 roller adjustable down pressure

– Robotic Stacking System can gently transfer 4 or 5 rolls of weak turf to pallets with our exclusive Gripper Head

– OEM Deluxe Cab includes tinted windows, interior climate control and training seat

– 16” / 23” / 24” Cutting Widths

– Automatic Pallet Injector can accommodate double sided pallets and holds approximately 18 pallets

– Electronic Auto-Steer with micro adjustment

– All Wheel Drive with Traction Control

– 127 HP Diesel Caterpillar Engine

– Scrap roll eject system (on the go)

– Squeeze function on upper layers

– Adjustable stacking pressure

– Pallets may be dropped on the go or easily backed out of the way of the cut line

– Fully automated Auto Drive control for maintaining harvest ground speed

– Electronically adjustable cut-off length

– Proven automatic flap control

– LED lighting

– Finger tip controls for simple field adjustments

– Fits in container for shipping

– Excellent visibility of cutter, conveyor and piling area

– Operation and diagnostic screen

– Back-up camera

– Multiple stacking patterns including flat and pyramid tops

– Automatic moving piling walls produces a tighter pallet

– Excellent machine stability and floatation on soft ground

– Chassis tie downs for easy transport

4000 Specifications:

Conveyor …………………………………………………………………………. Rubber Mat

Cutting Head ……………………………………………………………………. Full Floating Cutter Head

Width of Cut …………………………………………………………………….. 16” (406 mm) / 23” (584mm) 24” (610 mm)

Length of Cut …………………………………………………………………… up to 100” (2540 mm)

Thickness of Cut ………………………………………………………………. Hydraulically Adjustable

Pallet Size ……………………………………………………………………….. 48” (1.2 m) x 48” (1.2 m)

Cutter Drive………………………………………………………………………. Variable Hydraulic

Conveyor Drive………………………………………………………………….. Variable Hydraulic

Cutting Blades …………………………………………………………………. Standard with Fingers / V-Blade

Construction …………………………………………………………………….. High Strength Steel Weldment

Total Weight …………………………………………………………………….. 18641 lbs. (8955 kg.)

Overall Length …………………………………………………………………. 296” (7518 mm) (Less Ski)

Overall Width …………………………………………………………………… 124” (3150 mm) (Less Toe Guard)

Shipping Width ………………………………………………………………… 91” (2312 mm)

Overall Height…………………………………………………………………… 104” (2642 mm) (Less Strobe) (112.5” w/Mast Sensor)

Pallet Configuration……………………………………………………………. Pyramid or Flat Top (Upper Level Squeeze Function)

Flap Control……………………………………………………………………… Automatic

4000 Engine, Tire & Cab Specifications:
Caterpillar ………………………………………………………………………… I-4. Diesel – Four Stroke Cycle

Displacement …………………………………………………………………… 4.4L (269 cu.in.)

Aspiration ……………………………………………………………………….. Turbocharged After-cooled

Horsepower ……………………………………………………………………… 127 HP @ 2200rpm

Torque …………………………………………………………………………….. 309 lb-ft. @ 2200rpm – 380 lb-ft. @ 1400 rpm

Front Tires ……………………………………………………………………….. 550/45 R22.5 Flotation (Optional 380/75 R20)

Rear Tires ………………………………………………………………………… 650/55 R22.5 Flotation Radial

Cab …………………………………………………………………………………. Deluxe Cab

Seat…………………………………………………………………………………. Deluxe Swivel Air Suspension

Upgrades:

Optional Front Tires
Spare Parts Kit
